• Chrome front bumper w/Spectra Gray cover
• Chrome rear bumper w/step pad
• Dark argent air dam
• Body-side molding w/chrome trim
• Wheel opening flares
• Deluxe chrome grille
• Dual composite halogen headlamps w/auto on/off
• Daytime running lamps
• Cargo area lamp
• Dual chrome fold-a-way pwr mirrors
• Solar-Ray tinted glass (all windows)
• Swing-out rear quarter windows
• Dual rear access doors hinged to rear of cab
• Intermittent windshield wiper system
• Removable tailgate w/badge name/decal
• Floor covering/under dash insulation

• LS decor
• 3-passenger custom cloth 40/20/40 reclining split bench seat w/center fold-down storage armrest, manual driver/passenger lumbar
• 3-passenger folding rear bench seat w/matching trim
• Color-keyed full floor carpeting w/front/rear rubber floor mats
• Leather-wrapped steering wheel
• Tilt wheel
• Passlock theft deterrent security system
• Message center warnings-inc: system malfunction, trans overheat, low fuel, low coolant, vehicle security, oil level/temp/pressure/change needed
• Warning tones-inc: key-in-ignition, seat belt, headlamp, turn signal
• Cruise control
• Auto pwr door locks/windows w/backlit switches
• Keyless entry w/content theft alarm
• Illum entry
• Air conditioning
• Heater/defogger w/side window defoggers
• ETR AM/FM stereo w/compact disc-inc: seek-scan, digital clock, auto tone control, theft lock, speed compensated volume, enhanced performance speaker system
• Dual dash cup holders
• Dual covered pwr points
• Color-keyed soft vinyl door trim panels w/cloth inserts-inc: map pockets w/carpeted trim, door reflectors
• Overhead console
• Color-keyed cloth headliner
• Dual color-keyed padded cloth sunshades w/driver storage clip, passenger mirror
• Passenger assist handles
• Lighting-inc: dome w/delayed entry feature, ashtray, glove box, underhood
• Dual foldaway coat hooks

• Four-wheel anti-lock brake system
• Driver & front passenger airbags w/passenger side deactivation switch
• Manual lap/shoulder safety belts, front/rear outboard seat positions
• Manual lap safety belts, center seat positions
• Head restraints at outboard seating positions
• Daytime running lamps
• Side door guard beams
• High/low note horn

6.0L (364) SFI V8 (VORTEC) ENGINE

• (STD)

• Preferred Equipment Group 1SB
• 3.73 Axle Ratio
• Locking Differential
• 40/20/40 Split Front Seat
• Reclining Bucket Seats
• Custom Cloth Seat Trim
• 6-Way Power Driver/Passenger Seats
• Fleetside Body Ordering Code
• Engine Oil Cooling
• Deep Tinted Solar-Ray Glass
• ETR AM/FM Stereo w/Cassette & CD
• Skid Plate Package
• Standard Suspension
• HD Suspension
• AutoTrac Active Transfer Case
• Floor Console
• Fourth Door
• 4-Wheel Disc Brakes
• Front Center Armrest w/Storage
• Front beverage holders
• Variably intermittent wipers
• Tilt steering wheel
• Sport steering wheel
• Speed-sensing steering
• Speed control
• Security system
• Remote keyless entry
• Rear step bumper
• Power windows
• Power steering
• Power door mirrors
• Passenger vanity mirror
• Passenger door bin
• Passenger cancellable airbag
• Panic alarm
• Overhead console
• Leather steering wheel
• Illuminated entry
• Fully automatic headlights
• Front wheel independent suspension
• Front reading lights
• Front anti-roll bar
• Dual front impact airbags
• Driver door bin
• Chrome wheels
• CD player
• Bumpers: chrome
• Bodyside moldings
• AM/FM radio
• ABS brakes
• Voltmeter
• Tachometer
• Air Conditioning
• 6 Speakers

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 15.3
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4410
• Gross Axle Wt Rating - Rear (lbs): 6000
• Curb Weight - Front (lbs): 3249
• Curb Weight - Rear (lbs): 2283
• Gross Vehicle Weight Rating Cap (lbs): 8600
• Gross Combined Wt Rating (lbs): 13,500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5,000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 11,000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1500
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 11,000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2500
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 4500
• Spring Capacity - Rear (lbs): 6000
• Axle Type - Front: Hypoid
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4500
• Axle Capacity - Rear (lbs): 6000
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 32
• Shock Absorber Diameter - Rear (mm): 32
• Stabilizer Bar Diameter - Front (in): 1.42
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 13.0 x 1.14
• Tires
• Front Tire Order Code: QIZ
• Rear Tire Order Code: QIZ
• Spare Tire Order Code: QIZ
• Front Tire Size: LT245/75R16
• Rear Tire Size: LT245/75R16
• Spare Tire Size: LT245/75R16
• Front Tire Capacity (lbs): 2205
• Rear Tire Capacity (lbs): 3042
• Spare Tire Capacity (lbs): 2205
• Revolutions/Mile @ 45 mph - Front: 680
• Revolutions/Mile @ 45 mph - Rear: 680
• Revolutions/Mile @ 45 mph - Spare: 680
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Chrome
• Rear Wheel Material: Chrome
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 15.0
• Steering Ratio (:1), At Lock: 13.0
• Turning Diameter - Curb to Curb (ft): 52.3
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 157.5
• Length, Overall w/o rear bumper (in): 246.5
• Width, Max w/o mirrors (in): 79.7
• Height, Overall (in): 74.5
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 52.0
• Front Bumper to Back of Cab (in): 138.7
• Cab to Axle (in): 55.9
• Cab to End of Frame (in): 97.6
• Ground to Top of Load Floor (in): 34.5
• Frame Width, Rear (in): 42.1
• Ground Clearance, Front (in): 8.3
• Ground Clearance, Rear (in): 8.1
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.6
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 60.2
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 60.6
• Cargo Volume (ft³): 70.7
• Ext'd Cab Cargo Volume (ft³): 49.7
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 38.4
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Second Hip Room (in): 61.5
• Summary
• Vehicle Name: Chevrolet Silverado 2500
• Body Style: Ext Cab 8' Fleetside
• Body Code: E63
